Horizontal & Vertical Blender
JHLR vertical ribbon mixer

Mixed volume of material

Mixer power

FOREWORD
\

1、Agitating Parts
The agitating parts of this series mixer are relatively simple with helical blades out of a principal axis driving the material from up to down and outside spiral belt distributed by cone-shape, jointing closely with cylinder to lift the material from bottom to up.

2、Volume
Cone-shape spiral belt mixer offers the advantages of compact structure, low energy consumption, soft mix movement and few friction heat, usually used in the mix environment of low mix volume and high value added with small volume of device.

3、Cooling and heating
Cool or heat the materials through injecting the cold or hot medium into the jacket which is added to the outside of the mixer cylinder. Pump industrial water for cooling and steam or heat oil heated by electricity for heating.

4、Feeding Mode
The cover of this mixer can be made as full open type in the small scale production place in order to feed material manually and clean the interior of device by users.

5、Discharging Mode
Due to the mixing feature, the cone-shape spiral belt mixer is suitable for mixing the liquid materials, usually applying to agitate the mixed dye and pesticide. Under this condition, it needs to change discharge valve into butterfly valve or ball valve.

6、Self-heating
When requiring self-heating, our company usually plugs the heating thermocouple into the bottom of the jacket full of heat oil to meet the heating requirement at low temperature. In addition, the conditioned users can heat the heat oil outside and then pump the oil into jacket to ensure that the materials can be heated uniformly.






Production Introduction
 Technical Parameters

Model\Project
Total Volume(M³)
Loads coefficient
Electrical machiney power(KW)
Size(mm)× Max-diameter ×High
Equipment weight (kg)
JHLR-300
0.3
0.4-0.6
2.2
φ920 x 1929
320
JHLR-500
0.5
0.4-0.6
4
φ1140 x 2322
410
JHLR-1000
1
0.4-0.6
7.5
φ1480 x 2869
900
JHLR-1500
1.5
0.4-0.6
11
φ1633 x 3140
1200
JHLR-2000
2
0.4-0.6
11
φ1816 x 3489
1300
JHLR-3000
3
0.4-0.6
15
φ2040×3760
2400
JHLR-4000
4
0.4-0.6
18.5
φ2250×4425
2500
JHLR-6000
6
0.4-0.6
22
φ2548×4940
2850
JHLR-8000
8
0.4-0.6
30
φ2780×5360
4250
JHLR-10000
10
0.4-0.6
37
φ3018×5815
5200
JHLR-12000
12
0.4-0.6
45
φ3204×6100
5800
JHLR-15000
15
0.4-0.6
55
φ3442×6540
6300
