Double Cone Chemical Mixer
JHW Double Shafts Paddle Mixer Series

Mixed volume of material

Mixer power

FOREWORD
The advantages of the mixer

The advantage of this mixer is wide application, high mixing precision, short mixing time.

JHW series is a high precision mixing equipment, wide adaptive to all kinds of mixtures,it also can mix the mixtures evenly which have big differences in proportion, matching, particle diameter.For mixtures that ratio difference reaches to 1:1000~10000,it also can mix well.There is a crushing plant equipped in the machine,so it can partial crush the particle materials.


The design for full opening discharging ensures little residua and good sealing as well as short discharging time.
Production Introduction
Mixer Parameters
Model Total Volume (M³) Batch Capacity
(kg)
Power (KW) Dimension (L×W×H) mm Weight (Kg)
JHW50 0.05 20~30 1.5 1390×655×1184 270
JHW260 0.26 80~90 4 1340×1210×933 300
JHW300 0.3 120~180 4 1475×1375×1240 490
JHW500 0.5 200~300 7.5 1715×1610×1360 870
JHW1000 1 400~600 11 1940×1870×1610 1200
JHW1500 1.5 600~900 15 2190×2020×1780 1600
JHW2000 2 800~1200 18.5 2280×2270×1940 2950
JHW3000 3 1200~1800 22 2410×2490×2070 4350
JHW4000 4 1600~2400 22 2750×2750×2360 4650
JHW5000 5 2000~3000 37 3020×3070×2580 6300
JHW6000 6 2400~3600 45 3140×3110×2710 7250
JHW10000 10 4000~6000 55 3620×3640×3110 8400
JHW15000 15 6000~9000 55 5010×3780×3260 10000
JHW20000 20 8000~12000 75 5370×4140×3410 13000


Equipment and Constitution Picture
